Vfd rubber-sheathed flexible cable for coal mining applications

Products Mode:

Power supply connection for coal mine frequency conversion devices and similar underground mobile equipment with rated voltage up to 1.9/3.3 Kv.

Inquery Now

Vfd rubber-sheathed flexible cable for coal mining applications

Vfd rubber-sheathed flexible cable for coal mining applications

Description

Parameter

Conductor Material: Copper
Insulation: EPR
Sheath Material: CPE Rubber
Shielding Type: Semiconductive Shield、Braid Shield
Rated voltage: 1.9/3.3kv and below
Flex Life: 9000 Times
Bending radius: Unshielded cables: ≥6×d (d = cable diameter).
Temperature Range: Operating temp.: ≤90℃
Certifications & Compliance: Q/CSHF 043

Properties

Maximum rated operating temperature of the cable conductor: 90℃.
Recommended permissible bending radius: minimum bending radius is 6 times the cable diameter.

Product description

Model	Name	Application
MVFP-0.38/0.66	Flexible rubber sheath mobile cable for coal mine frequency conversion equipment	Rated voltage 0.38/0.66Kv and below power interface for coal mine variable frequency drive (vfd) devices and similar underground mobile equipment.
MVFP-0.66/ 1. 14	Flexible rubber sheath mobile cable for coal mine frequency conversion equipment	Rated voltage 0.66/1.14Kv and below power integration for mining vfd systems and analogous subterranean movable installations.
MVFP- 1.9/3.3	Flexible rubber sheath mobile cable for coal mine frequency conversion equipment	Rated voltage 1.9/3.3Kv and below electrical connectivity for coal mine frequency converters and related underground mobile units.
MVFPT-0.38/0.66	Metal shield flexible rubber sheath mobile cable for coal mine frequency conversion equipment	Rated voltage 0.38/0.66Kv and below power junction for mining vfd applications and comparable below-ground transportable devices.
MVFPT-0.66/ 1. 14	Metal shield flexible rubber sheath mobile cable for coal mine frequency conversion equipment	Rated voltage 0.66/1.14Kv and below power interface for colliery frequency conversion equipment and similar sub-surface mobile machinery.
MVFPT- 1.9/3.3	Metal shield flexible rubber sheath mobile cable for coal mine frequency conversion equipment	Rated voltage 1.9/3.3Kv and below electrical linkage for mine vfd installations and analogous drift-moving apparatus.
