Silicon rubber insulation control cable

Products Mode:

This product is applicable to the ac rated voltage 4500/750v and below mobile or fixed devices installation.Cable has good flexibility,with high temperature resistance,corrosion resistance,withstand voltage and other advantages

Inquery Now
Next
Description
Parameter
  • Conductor Material: Copper
  • Insulation: Silicone Rubber
  • Sheath Material: Silicone Rubber
  • Shielding Type:Unshielded、Braid Shield
  • Rated voltage: 450/750v
  • Bending radius: Minimum bending radius: ≥6×d (d = cable diameter)
  • Temperature Range:
    Operating temp.: -60℃ to +180℃
    installation temp.: ≥-40℃
  • Certifications & Compliance:IEC 60227/60245
Properties
  • The environment temperature of the cable is-60~+180℃;The minimum bending radius of cable should be not less than 6 times of cable diameter.
Product description
  • Model
    Name
    Application
    KGGR Copper core silicon rubber insulation silicon rubber sheath control flexible cable For mobile equipment interconnections in harsh environments (power plants, metallurgy, chemical plants, ports).
    KGGRP Copper core silicon rubber insulation silicon rubber sheath braided shield control flexible cable
