Photovoltaic cable

Products Mode:

This product is suitable for class ll under security level,the maximum allowed rated voltage 1.8Kv (core to core,non-grounded system)direct voltage,used in pv system dc side,can also be applied to pv system power frequency rated voltage 0.6/1 Kv ac voltage.In pv system,the solar energy is directly change into electricity.Cable resistant to uv,temperature,and can be used as a separate connection to the solar batteries,because cable has good climate resistance,cable can also be used outdoors,but not laying directly buried underground and underwater.

Inquery Now
Description
Parameter
  • Conductor Material: Copper
  • Insulation: XLPO
  • Sheath Material: XLPO、LSZH
  • Rated voltage: 1.8kv and below
  • Bending radius: ≥6D
  • Temperature Range: -40℃ to R16120℃
  • Certifications & Compliance: IEC 62930
Properties
  • The highest permissible working temperature of conductor:120℃;
    The minimum permissible working ambient temperature of cable:-40℃;
    The minimum bending radius of cable should be not less is 6 times of its diameter.
Product description
  • Model
    Name
    Application
    PV1-F Low-smoke halogen-free flame retardant cross-linked polyolefin insulation
    and sheathed flexible cable for photovoltaic modules    		 Pv system cables for panel-to-combiner/inverter connections.
    H1Z2Z2-K Copper conductor irradiated cross-linked polyolefin insulation irradiated cross-linked polyolefin sheath photovoltaic module cable Pv system cables for panel-to-combiner/inverter connections.
