Multi-core mobile flexible cable for electric block

Products Mode:

This product is applied to the ac rated voltage 300/300v,300/500v and below,connecting various frequently movable electrical equipment copper core rubber insulation sheath flexible cable,especially applied to electric block,traveling crane and flaw detection equipment.

Inquery Now
Description
Parameter
  • Conductor Material: Copper
  • Insulation: EPR
  • Sheath Material: CPE Rubber
  • Shielding Type: Unshielded、Braid Shield
  • Rated voltage:300/300v,300/500v and below
  • Flex Life:15000 Times
  • Bending radius:
    Unshielded cables: ≥6×d (d = cable diameter).
    Shielded cables (bs): ≥8×d
  • Temperature Range: Operating temp.: ≤65℃
  • Certifications & Compliance: Q/EAAF063
Properties
  • The long term working temperature of the conductor is 65℃;
    The bending radius of the cable should be not less than 6 times of its diameter.
Product description
  • Model
    Name
    Application
    YR Epr insulation rubber sheath multi-core mobileflexible cable Connected with ac300/300v,300/500v and belowvarious mobile electric equipments
    YRP Epr insulation rubber sheath metallic shieldmulti-core mobile flexible cable Connected with ac300/300v,300/500v and belowvarious mobile electric equipment with shield
    YRF Epr insulation rubber sheath multi-core mobileflexible cable Connected with ac300/300v,300/500v and belowvarious mobile electric equipments
    YRFP Epr insulation rubber sheath metallic shieldmulti-core mobile flexible cable Connected with ac300/300v,300/500v and belowvarious mobile electric equipment with shield
