Mining explosion-proof double-layer armored aluminum alloy cable

Products Mode:

Double-layer steel tape armor resists crushing and rodent damage, engineered for direct burial, mining, and harsh environmental applications.

Inquery Now

Mining explosion-proof double-layer armored aluminum alloy cable

Mining explosion-proof double-layer armored aluminum alloy cable

Description

Parameter

Conductor Material: Aluminum Alloy
Insulation: XLPE
Sheath Material: PVC、PE、Interlocking Armored
Shielding Type: Copper Tape Screening、Copper Wire Screening
Rated voltage: 26/35kv and below
Bending radius:
Unarmoured: 15d (multi-core), 20d (single-core)；
armoured: 12d (multi-core), 15d (single-core)
Temperature Range: 90℃ (long-term), 250℃ (short-circuit)
Certifications & Compliance: IEC 62930

Properties

The long time working temperature of conductor should not be higher than 90℃;
The maximum working temperature of conductor should not exceed 250℃when short circuit(max 5s);
The minimum bending radius of armored cable is 7 times of the cable diameter.

Product description

Model	Name	Application
YJLHV22	Aluminum alloy conductor cross-linked polyethylene insulated steel tape armored PVC sheathed power cable	For conventional power t&d and renewable energy sectors.
YJLHY23	Aluminum alloy conductor cross-linked polyethylene insulated steel tape armored polyethylene sheathed power cable	For conventional power t&d and renewable energy sectors.
