Environmental new type seclusion type (flexible)mineral insulated cables

Products Mode:

This new environmental protection isolated(flexible)mineral insulated fire proof power cable with the rated voltage of 0.6/1Kv and the below has the function of good anti-rat,anti-ant,anti-radiation to ensure the stability,long life and durability of the cable.The advantages of low working temperature,low line loss, strong anti-overload ability,long service life,high safety are especially suitable for the projects with the requirements of environmental protection.

Inquery Now

Prev Next

Environmental new type seclusion type (flexible)mineral insulated cables

Description

Parameter

Conductor Material: Copper
Insulation: Mineral Mica Tape、PVC
Sheath Material: Aluminium Sheath、LSZH
Rated voltage: 0.6/1kv and below
Bending radius: D<=12,6d;12<D<20,10d;20<D<40,15d；d>=40,20d
Temperature Range: 750℃-950℃ (fire resistance)
Certifications & Compliance: Q/CSHF 012/Q/EAAF 216

Properties

The long time working temperature of conductor should not be higher than 90℃;
The maximum working temperature of conductor should not exceed 250℃ when short circuit(max 5s);

Product description

Model

Name

Application

NG-A(BTLY) Seclusion type mineral insulated cables Fire survival cables for emergency circuits in crowded spaces.

Model	Name	Application
NG-A(BTLY)	Seclusion type mineral insulated cables	Fire survival cables for emergency circuits in crowded spaces.
